Von Duprin EL9827L-NL-16 3 313 LHR Click To Copy (aria-label: Click to copy MPN)

Surface-mounted, UL-listed vertical rod device for single or double doors, available in 9827 (smooth case) or 9927 (grooved case) models. Suitable for stock hollow metal doors with 86 or 161 cutouts, it's ANSI A156.3 - 2008 Grade 1 rated. Non-handed, but can be configured with SD, SS, or WS options. Vertical rod and latch guards protect against impacts. See opposite page for trim and function details.

• Initial Device Functions: Ships with EO/DT/NL. Field customization available. For TP, K, or L, remove NL drive screw
• Door Sizes: 2" x 2" (610 mm) (shipped without UL label) | 3' 2'4' to 3' (711mm to 914 mm) | 4' 2'10" to 4' (864 mm to 1219 mm)
• Device Centerline Height: 395 /8" (1006 mm) from finished floor
• Center Case Dimensions: 8" x 2 3/4" x2 3/8" (203mm x 70mm x 60mm)
• Mechanism Case Dimensions: 2 1/4" x 2 1/4" (57mm x 57mm)
• Pushbar Projection: Neutral - 3 13/16" (97 mm) | Depressed - 3 1/16" (78 mm)
• Latch Bolt: Deadlocking, anti-friction top & bottom, 5 /8" (16mm) throw
• Recommended Door Undercut: 1 /4" (7mm)
• Latch Case Dimensions: 4 1/2" x 2 1/8" x 1 1/2" (114mm x 54mm x 38mm)
• Vertical Rods: 1/2" square tubing, standard for 7' doors. Top: 34 15/16" (887mm), Bottom: 31 1/2" (794mm). Extensions & one-piece top rod available for larger doors
• Fasteners & Sex Bolts: SNB screw pack for 1 3/4" to 2 1/4" thick doors. 325 SNB for top & bottom latch. Optional 425 SNB available
